Logistics Q345B Tri Axle 60T Drop Side Semi Trailer

    Buy cheap Logistics Q345B Tri Axle 60T Drop Side Semi Trailer from wholesalers

    Buy cheap Logistics Q345B Tri Axle 60T Drop Side Semi Trailer from wholesalers
    • Buy cheap Logistics Q345B Tri Axle 60T Drop Side Semi Trailer from wholesalers

    Logistics Q345B Tri Axle 60T Drop Side Semi Trailer

    Ask Lasest Price
    Brand Name : CIMC
    Model Number : Side Wall Semi Trailer
    Certification : CE
    Price : USD 9700-12500/Unit
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300 Unit/Units per Month
    Delivery Time : 25-30 Works
    • Product Details
    • Company Profile

    Logistics Q345B Tri Axle 60T Drop Side Semi Trailer

    CIMC Tri Axle 60Ton Drop Side Semi Trailer Manufacturer For Sale


    Product Description:

    Cargo semi trailer for sale was popular by logistics companies as its multipurpose application. It uses to load a wide range of products and materials, like sand, bags, poultry, etc.

    Also, some bulk cargo, very widely used in the transportation industry. The sidewall flatbed trailer can be used to load the containers after adopt the container locks for it.

    CIMC High Side Trailer is designed with detachable side walls and a bulkhead in front to protect the cargo inside. It is widely used to haul general cargo, livestock and other bulk items. Waterproof cover and slider roof can be equipped as an option for valuable goods protection.

    ​This side wall semi trailer is designed to carry the bulk cargo also 20ft / 40ft container. It's equipped with 12 pcs twist lock.


    Details of bulk cargo semi trailer:

    1.Electrical system: The drop side semi trailer is equipped with an international electrical system that is compatible with the tractor. There are electrical connector sockets on the front beam of the frame.
    2.Suspension system: Suspension device support is welded on the back and the lower part of the longitudinal beam and support device support is provided on the lower front part.
    3.Axles and wheels: Three axle assemblies of the same structure are installed under the suspension system.
    4.Support leg: In order to make the semi-trailer reliably parked after leaving the truck head, the front end of the frame is equipped with two support legs that are linked left and right or left and right.

    Specification of Cargo Semi Trailer:

    L*W:12500mm*2500mm
    Sidewall Height:600mm
    Max. Payload:<60T
    Application:Coal/Cargo/Containers Loading
    Material:Q345B Steel
    Bottom Platform:3mm-thick checkered plate
    King Pin:JOST brand 2.0 or 3.5inch(bolted or welded type)
    Support leg:JOST brand
    Suspension:Airbag / Mechanical / Bogie suspension
    Axles:FUWA/BPW/CIMC/other
    Tires:12.00R22.5/315 80R22.5(Specially designed and for oversea markets)
    Brake System:WABCO
    Electrical System:24-volt lighting system

    Tri Axle Cargo Semi Trailer

    3 axle cargo trailer

    dry cargo trailer for sale
